Product centerHOME > Product description > Ceramic 3535 SMD
3535 White LED 90deg
Product Feature:
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★Good bright spots and High bright
Product Use:
★Car Light,Flash Light,Decorative Light
★Street Light,Aquarium Light,etc
★Adopt well-known vender’s chip package.
★99.99% gold wire welding
★Good bright spots and High bright
Product Use:
★Car Light,Flash Light,Decorative Light
★Street Light,Aquarium Light,etc
Juhong new product, 90deg 3535 ceramic led,welcome to consult!!
规格Datasheet
| 型号 Part No. |
功率 Power (W) |
色温 CCT (K) |
光通量 Luminous (lm) |
电压 Voltage (V) |
电流 Current (mA) |
角度 Angle (deg) |
| JH-3535W9P35 | 1 | 6000-8000 | 100-130 | 3.0-3.4 | 350 | 90 |
| JH-3535WW9P35 | 1 | 2800-3400 | 100-130 | 3.0-3.4 | 350 | 90 |
| JH-3535W9S40 | 3 | 6000-8000 | 240-280 | 3.2-3.6 | 700 | 90 |
| JH-3535W9S55 | 3 | 6000-8000 | 280-320 | 3.2-3.6 | 700 | 90 |
| JH-3535WW9L48 | 3 | 2800-3400 | 180-200 | 3.2-3.6 | 700 | 90 |
| JH-3535WW9P45 | 3 | 2800-3400 | 230-280 | 3.2-3.6 | 700 | 90 |
